Getting Started

Note: If you need to install NRTK, see Installation.

NRTK consists of three main parts:

The following sections will guide you through setting up and using an example perturber.

Image Perturbation

The core of NRTK is based on image perturbation. NRTK offers a wide variety of ways to perturb images. scikit-image, Pillow, openCV, and pyBSM are used for various types of perturbation. The perturbation classes take an image and perform a transformation based on input parameters. The examples shown below focus on a pyBSM based perturber. To see examples of other perturbations, the perturbers notebook shows initialization and use of scikit-image, Pillow, and openCV perturbers.

For this example, we are going to use the PybsmPerturber from pyBSM. This perturber is useful for creating new images based on existing parameters. The PybsmSensor and PybsmScenario classes contain the parameters for an existing sensor and environment, respectively.

pyBSM Perturber Initialization

import numpy as np
import pybsm
from nrtk.impls.perturb_image.pybsm.scenario import PybsmScenario
from nrtk.impls.perturb_image.pybsm.sensor import PybsmSensor
from nrtk.impls.perturb_image.pybsm.perturber import PybsmPerturber

opt_trans_wavelengths = np.array([0.58-.08,0.58+.08])*1.0e-6
f = 4 #telescope focal length (m)
p = .008e-3  # detector pitch (m)
sensor = PybsmSensor(
    # required
    name                = 'L32511x',
    D                   = 275e-3, # Telescope diameter (m)
    f = f,
    p_x = p,
    opt_trans_wavelengths = opt_trans_wavelengths, #Optical system transmission, red  band first (m)
    # optional
    optics_transmission = 0.5*np.ones(opt_trans_wavelengths.shape[0]), #guess at the full system optical transmission (excluding obscuration)
    eta                 = 0.4, #guess
    w_x                  = p, #detector width is assumed to be equal to the pitch
    w_y                  = p, #detector width is assumed to be equal to the pitch
    int_time            = 30.0e-3, #integration time (s) - this is a maximum, the actual integration time will be, determined by the well fill percentage
    dark_current        = pybsm.dark_current_from_density(1e-5,p,p), #dark current density of 1 nA/cm2 guess, guess mid range for a silicon camera
    read_noise          = 25.0, #rms read noise (rms electrons)
    max_n               = 96000.0, #maximum ADC level (electrons)
    bitdepth            = 11.9, #bit depth
    max_well_fill       = .6, #maximum allowable well fill (see the paper for the logic behind this)
    sx                  = 0.25*p/f, #jitter (radians) - The Olson paper says that its "good" so we'll guess 1/4 ifov rms
    sy                  = 0.25*p/f, #jitter (radians) - The Olson paper says that its "good" so we'll guess 1/4 ifov rms
    dax                 = 100e-6, #drift (radians/s) - again, we'll guess that it's really good
    day                 = 100e-6, #drift (radians/s) - again, we'll guess that it's really good
    qe_wavelengths       = np.array([.3, .4, .5, .6, .7, .8, .9, 1.0, 1.1])*1.0e-6,
    qe                  = np.array([0.05, 0.6, 0.75, 0.85, .85, .75, .5, .2, 0])
)

scenario = PybsmScenario(
        name='niceday',
        ihaze=1, #weather model
        altitude=9000.0, #sensor altitude
        ground_range=0.0, #range to target
        aircraft_speed=100.0
)

perturber=PybsmPerturber(sensor=sensor, scenario=scenario, ground_range=10000)

In the example above, we have created a pyBSM perturber where the output image will have a ground_range of 10000m instead of 0m. The image below is the original image we will use for future perturbations.

_images/original_image.jpg — Original image of a tank

The code block below shows the loading of the image above and the calling of the perturber. It is important to note that the ground sample distance (or img_gsd) is another parameter the user will have to provide. The resulting image is displayed below the code block.

pyBSM Perturber Execution

import cv2

INPUT_IMG_FILE = './data/M-41 Walker Bulldog (USA) width 319cm height 272cm.tiff'
image = cv2.imread(INPUT_IMG_FILE)
img_gsd = 3.19/165.0 #the width of the tank is 319 cm and it spans ~165 pixels in the image

perturbed_image = perturber.perturb(image, additional_params={'img_gsd': img_gsd})

_images/10000_ground_range.png — Image of a tank with ground range of 10000m.

Any of the parameters in either PybsmSensor or PybsmScenario can be modified; however, only one parameter can be modified with one value using the basic perturber. The next section will cover modifying multiple parameters and multiple values.

Perturbation Factories

Building upon image perturbation, perturbation factories are able to take a range of values for parameter(s) and perform multiple perturbations on the same image. This allows for quick and simple generation of multiple perturbations. The scikit-image, Pillow, and openCV perturbers use the StepPerturbImageFactory and the pyBSM perturber uses the CustomPybsmPerturbImageFactory.

Continuing on from the previous example, the snippet below shows the initialization of a CustomPybsmPerturbImageFactory. The theta_keys variable controls which parameter(s) we are modifying and thetas are the actual values of the parameter(s). In this example, we are modifying the focal length (f) with the values of 1, 2, and 3. The modified images are displayed below the code block.

CustomPybsmPerturbImageFactory Initialization and Execution

from nrtk.impls.perturb_image_factory.pybsm import CustomPybsmPerturbImageFactory

focal_length_pf = CustomPybsmPerturbImageFactory(
    sensor=sensor,
    scenario=scenario,
    theta_keys=["f"],
    thetas=[[1, 2, 3]]
)

for idx, perturber in enumerate(focal_length_pf):
    perturbed_img = perturber(image, additional_params={'img_gsd': img_gsd})

_images/1_focal_length.png — Image of a tank with focal length of 1m.

_images/2_focal_length.png — Image of a tank with focal length of 2m.

_images/3_focal_length.png — Image of a tank with focal length of 3m.

Not only can you modify multiple values on one parameter, but you can also modify multiple parameters at the same time. The code block below shows the focal length and ground range variables being modified. The resulting images are displayed below the code block.

CustomPybsmPerturbImageFactory with Multiple Parameters

f_groung_range_pf = CustomPybsmPerturbImageFactory(
    sensor=sensor,
    scenario=scenario,
    theta_keys=["f", "ground_range"],
    thetas=[[1, 2], [10000, 20000]]
)

for idx, perturber in enumerate(f_groung_range_pf):
    perturbed_img = perturber(image, additional_params={'img_gsd': img_gsd})

Image of a tank with focal length of 1m and ground range of 10000m.	Image of a tank with focal length of 2m and ground range of 10000m.
Image of a tank with focal length of 1m and ground range of 20000m.	Image of a tank with focal length of 2m and ground range of 20000m.

Model Evaluation

NRTK provides functionality for evaluating models in the image classification and object detection tasks. The package also provides test orchestration functionality for performing evaluations over a sweep of parameters in order to test model response to varying severity of image degradation.

To see examples of image classification and object detection, the coco_scorer notebook from the examples directory shows different scoring techniques. For examples of model response to image degradations, there are two notebooks to check out. The simple_generic_generator notebook shows model response to image degradation through perturbers based on scikit-image, Pillow, and openCV. The simple_pybsm_generator notebook shows model response to image degradation through pyBSM-based perturbers.
